48V Lithium Battery Pack for off-grid Solar System
SKU: LFW51200
Nominal Voltage: 51.2V
Nominal Capacity: 100Ah
Kilowatt-hour(s): 5.12kWh
Design Life: +15 Years at 80% DoD
Communications: CAN/RS485/RS232(WIFl,bluetooth is optional)
High-efficiency 48V lithium battery pack for off-grid solar power. Ideal for home, or commercial solar systems.
10kw solar battery Product details
Features:
- Optimized for Off-Grid Solar Systems
This 48V lithium battery pack for off-grid solar system is engineered for continuous performance in remote, backup, and hybrid solar setups. - Compatible with Various Solar Setups
Whether you’re running a 48V lithium battery pack for solar panels, inverters, or energy hubs, this pack fits seamlessly into residential and commercial use. - High Capacity, Long Lifespan
Our LiFePO4 technology supports over 6000 cycles, delivering reliable energy for years—ideal for 48V solar storage systems. - Smart BMS for Safety and Monitoring
The built-in Battery Management System (BMS) protects against overcharge, discharge, temperature, and short circuits, ensuring safe operation in any solar environment. - Flexible Installation Options
Compatible with rack-mounted or wall-mounted installations, or pair it with other units to expand your solar energy storage.
Certifications and Compliance:
- Certified with CE, FCC, and CCC standards, ensuring quality and safety.
- Compliant with UN 38.3, UN 3480, MSDS for safe shipping.
Temperature Specifications:
- Wide operating temperature range from -20°C to 65°C for reliable performance in various environments.
Upgrade to our 51.2v 100ah LiFePO4 battery and experience a reliable and efficient power solution. Choose the perfect combination of voltage and capacity to suit your specific requirements. Invest in a power source that delivers performance, longevity, and peace of mind.
|
Model
|
LFR-4850/5150
|
LFR-48100/51100
|
LFR-48150/51150
|
FR-48200/51200
|
|
Standard Voltage
|
48VDc/51.2VDc
|
|||
|
Voltage
|
39.75-54.75VDc/42.4-58.4VDc
|
|||
|
Norminal Capacity
|
50Ah
|
100Ah
|
150Ah
|
200Ah
|
|
Rated Energy Capacity
|
2.4/2.56kWh
|
4.8/5.12kWh
|
7.2/7.68kWh
|
9.6/10.24kWh
|
|
Commumication Protocol
|
CAN/RS485/RS232/WIFI/4G/Blue Tooth
|
|||
|
Efficiency (at 0.5C)
|
98%
|
|||
|
Cell Self-Discharge
|
<5 %/ Month
|
|||
|
Maximum Allowed Modules in Parallel
|
15 (36/38.4kWh)
|
15 (72/76.8kWh)
|
15 (108/115.2kWh)
|
15 (144/153.6kWh)
|
|
Depth of Discharge
|
Up to 100%
|
|||
|
Useful Life
|
8-10 Years
|
|||
|
Cycle Life
|
6000 (@ 80% DoD)
|
|||
|
Protection
|
Over temperature, over current, short circuit, over-charging, over-discharging, Low voltage
|
|||
|
Charge Specifications
|
||||
|
Recommended Charge Current
|
25A
|
50A
|
75A
|
100A
|
|
Maximum Charge Current
|
50A
|
100A
|
100A
|
100A
|
|
Recommended Charge Voltage
|
54/57.6V
|
54/57.6V
|
54/57.6V
|
54/57.6V
|
|
Maximum Charge Voltage
|
54.75/58.4V
|
54.75/58.4V
|
54.75/58.4V
|
54.75/58.4V
|
|
Discharge Specifications
|
||||
|
Recommended Discharge Current
|
25A
|
50A
|
75A
|
100A
|
|
Maximum Discharge Current
|
50A
|
100A
|
100A
|
100A
|
|
Recommended Low Voltage Disconnect
|
41.25/44V
|
|||
|
Battery Low Voltage Protection
|
39.75/42.4V
|
|||
|
Battery Recovery Voltage
|
45/48V
|
|||
|
Mechanical Specifications
|
||||
|
Dimenstions
|
484*410*120mm
|
484*410*178mm
|
484*590*178mm
|
484*590*178mm
|
|
Weight
|
24.5/26.5kg
|
38.5/41kg
|
59/63kg
|
70.5/75kg
|
|
Terminal Type
|
M6
|
|||
|
Case Material
|
Industrial Grade Iron
|
|||
|
Enclosure Protection
|
IP20
|
|||
|
Installation
|
Cabinet
|
|||
|
Cell Type Chemistry
|
LiFePO4
|
|||
|
Compliance Specifications
|
||||
|
Certifications
|
CE,FCC, CCC
|
|||
|
Shipping Classification
|
UN 38.3. UN 3480, Class 9
|
|||
|
Temperature Specifications
|
||||
|
Discharge Temperature
|
-20~65℃
|
-20~65℃
|
-20~65℃
|
-20~65℃
|
|
Charge Temperature
|
0~55℃
|
0~55℃
|
0~55℃
|
0~55℃
|
|
Storage Temperature
|
-20~45℃
|
-20~45℃
|
-20~45℃
|
-20~45℃
|
Trust in LVFU’s commitment to excellence and innovation. Whether for home or industrial use, our LiFePO4 battery stands as a benchmark for quality and reliability. Make the smart choice for your power needs — choose LVFU Inquire now.
